*Construction documents
![](https://freight.cargo.site/t/original/i/b2c5951243ba6cd52399a9ce9e3e5d5f512ca0cd4aea71e88d665161619abc08/kendall-mann_construction-documents_Page_01.jpg)
“The course focuses on advanced methods of project delivery and construction documents incorporating digital technologies and investigating new models of linking design and construction processes. It introduces Building Information Modeling as one of the tools for realignment of the traditional relationships between the project stakeholders. Using a mixed-use residential, office and public building located in Los Angeles, students will analyze and develop the architecture by creating a detailed 3D digital model and a set of 2D construction documents specifically tailored for the design challenges of a mixed-use project.”
Course description from Pavel Getov and Kerenza Harris
![](https://freight.cargo.site/t/original/i/5322ea921d90962a212d3ba54a32141334b08cd871f3590a1776c65fe848c6fb/kendall-mann_construction-documents_Page_12.jpg)
![](https://freight.cargo.site/t/original/i/405a8e46cfa0be5895440a62f11f38b2394118e22dcbb11593c69026d7379b2c/kendall-mann_construction-documents_Page_13.jpg)
![](https://freight.cargo.site/t/original/i/1c64902ffa340d91241c627fce73f72e0987d2dcc688c9bcbb327522cc3425f4/kendall-mann_construction-documents_Page_14.jpg)
![](https://freight.cargo.site/t/original/i/cde105929ae1d205719eccc08fcc19e07bff1b51068ec5fd763a0cd0a7011fd0/kendall-mann_construction-documents_Page_15.jpg)
![](https://freight.cargo.site/t/original/i/1836ab4716b520dde4c05934b5677a4888f4c4084a0015278d3ad3634162c5e7/kendall-mann_construction-documents_Page_16.jpg)
![](https://freight.cargo.site/t/original/i/468720191a6f6c0685fd79aa74c1acb686d8eea37cb6fa7dd861c6cfbbfbbfa5/kendall-mann_construction-documents_Page_17.jpg)
![](https://freight.cargo.site/t/original/i/fd9fbbf78f445619cb14e8bbc47ffb50dd839bef052a07e45afad01b4ee9070c/kendall-mann_construction-documents_Page_18.jpg)
![](https://freight.cargo.site/t/original/i/0b9a95ab49a6f41386bc5a3e07755f46af1268efc03989b2cf4f0b68f2a817a1/kendall-mann_construction-documents_Page_19.jpg)
![](https://freight.cargo.site/t/original/i/613b96bc7976b0fbcff103869d8fafee3a2d8f87c56f6d149d84f508cea30ed4/kendall-mann_construction-documents_Page_20.jpg)
![](https://freight.cargo.site/t/original/i/73516084fec517b484599040b1122f7cb7d910a09af0bac5460fd1bae84baafd/kendall-mann_construction-documents_Page_21.jpg)
![](https://freight.cargo.site/t/original/i/0832f467fe95b4167615f2d840c7ed27cf364f00798dd791f1f62cc7d3240cbf/kendall-mann_construction-documents_Page_22.jpg)
![](https://freight.cargo.site/t/original/i/bd5f7849250074efb5a802502ad1229546c3db5131b46b0278aad3fb6b5d90be/kendall-mann_construction-documents_Page_23.jpg)
![](https://freight.cargo.site/t/original/i/823e21f74f411d53963eba190c91bb330404767aa5616c418a5f5474a1dc778e/kendall-mann_construction-documents_Page_24.jpg)
![](https://freight.cargo.site/t/original/i/7107e9f75336bf24b7868a60e4ace5922ea8a1e763b83f66c66a2e8eb63b677f/kendall-mann_construction-documents_Page_25.jpg)
![](https://freight.cargo.site/t/original/i/bdadae3c93ddca1579a50896d6c826f0b14858b6710e7fa0ca91d1abd5145d2e/kendall-mann_construction-documents_Page_26.jpg)
![](https://freight.cargo.site/t/original/i/e2b34ff5189a01e1a4672741b6827522b1ac479744325a7a14ae18956abe591a/kendall-mann_construction-documents_Page_27.jpg)
![](https://freight.cargo.site/t/original/i/2a658ae2412d10f9f83425b0087f1ed84918bdc33501adcf0e58ac085da8ed3e/kendall-mann_construction-documents_Page_28.jpg)
![](https://freight.cargo.site/t/original/i/0e3154e1d2b25e88a302074045978a9e99bc4cf95c817043c494001889171620/kendall-mann_construction-documents_Page_29.jpg)
![](https://freight.cargo.site/t/original/i/5521efb150fce815024de0aef6fc5c3900e2feab393236664947e7814313a834/kendall-mann_construction-documents_Page_30.jpg)
![](https://freight.cargo.site/t/original/i/86bee94b12a5c05cbe6d48902d464b856bba739c0933e648dbe7ee7cc36be233/kendall-mann_construction-documents_Page_31.jpg)
![](https://freight.cargo.site/t/original/i/3490406053e2629df907820b0181fa76a73449855ee6e329b215979dba7dcb6c/kendall-mann_construction-documents_Page_32.jpg)
![](https://freight.cargo.site/t/original/i/27254b39cb5bee6331fca6ec169fdead4f766d446013518ca999b77dee1c6cce/kendall-mann_construction-documents_Page_33.jpg)
![](https://freight.cargo.site/t/original/i/229c57bc888f2565fd8b1f08ca951b399872df4951118b574b63aa2546ebac11/kendall-mann_construction-documents_Page_34.jpg)
![](https://freight.cargo.site/t/original/i/6c99aca7cd8bce55c90c932a42481e630d60ee1a244016f2ce099b011da99091/kendall-mann_construction-documents_Page_35.jpg)
![](https://freight.cargo.site/t/original/i/c97ed373910fc47f92fb2e23bf6cafb6b3a23a52ff0acf14a3a95e8069f7f6a1/kendall-mann_construction-documents_Page_36.jpg)
![](https://freight.cargo.site/t/original/i/5bf6e0dec05f8841c69ef15359127fb76705533d0f1c395d41013438b53ca256/kendall-mann_construction-documents_Page_37.jpg)
![](https://freight.cargo.site/t/original/i/4cc969ae9b9f14c97f73a94b9d911a4f7f49b1af60ab8410bcbb3dacd273bd39/kendall-mann_construction-documents_Page_38.jpg)
![](https://freight.cargo.site/t/original/i/0fb7c4c000ef9c455655f8b97c07a142667136214fae29eb8c316a436860b3f9/kendall-mann_construction-documents_Page_39.jpg)
![](https://freight.cargo.site/t/original/i/cac4bbb9818c9f71549600cf440346752511c10d1d3025d95d1bd4ed4a439d39/kendall-mann_construction-documents_Page_40.jpg)
![](https://freight.cargo.site/t/original/i/c355bffe8713f1fd26e577ea6e1fa9c335cf6ddfb29312df0b81f514ad61c130/kendall-mann_construction-documents_Page_47.jpg)
![](https://freight.cargo.site/t/original/i/f5ddb288a778241de7f38278a17d0a971df9fea886c4b889f11cbaa4fdbe0027/kendall-mann_construction-documents_Page_02.jpg)
![](https://freight.cargo.site/t/original/i/eb6afb6d11ba4762009fc558334c529effb035331ec4dfdc26ccd4fbd7050f6c/kendall-mann_construction-documents_Page_03.jpg)
![](https://freight.cargo.site/t/original/i/41ec5e321f5296529bbf5d490b2f7a3826b712047c6e1df3d85783e32e747f93/kendall-mann_construction-documents_Page_04.jpg)
![](https://freight.cargo.site/t/original/i/552a4ac46fd2441c9216100a64ef67e133b9f8eecc4fbea2a693e8f1f088d0a3/kendall-mann_construction-documents_Page_05.jpg)
![](https://freight.cargo.site/t/original/i/be20c5e54cb6f484d356556e4df3ddeaa297afbb52bcf82aebc467b366708ecd/kendall-mann_construction-documents_Page_06.jpg)
![](https://freight.cargo.site/t/original/i/c70e58a154720d9d76b553ddeb06a4691290a67b6feb3edc2ce27b66438f55d4/kendall-mann_construction-documents_Page_07.jpg)
![](https://freight.cargo.site/t/original/i/7b08b9d58c8a85471ef0b8107e373a0c9fbb0d899b7f06c98152a3748a4a5977/kendall-mann_construction-documents_Page_08.jpg)
![](https://freight.cargo.site/t/original/i/7906f8973d563f52806b9825b5da00493282bd136e97abe0438d6c4a56a97552/kendall-mann_construction-documents_Page_09.jpg)
![](https://freight.cargo.site/t/original/i/fe42f33f4d2358a6c5f7d6f2895b994c006a60f5fe0ff7be7b0e25f34c525ee7/kendall-mann_construction-documents_Page_10.jpg)
![](https://freight.cargo.site/t/original/i/abef3a92eb6cfad9b8f7398dbeceb1ad2a9af53b29339811f3f4aae79c666789/kendall-mann_construction-documents_Page_11.jpg)
![](https://freight.cargo.site/t/original/i/fbfa0d82e7bd1cf3d5bb3d587798a428964635ddba5eec316a33958f55f59b13/kendall-mann_construction-documents_Page_41.jpg)
![](https://freight.cargo.site/t/original/i/1a86fd62eee341898275d3e9afb47992384a99c20e7eec30afe21165466af5b6/kendall-mann_construction-documents_Page_42.jpg)
![](https://freight.cargo.site/t/original/i/c15a22f13434398b785378e7706253b890b01a8e70435a63c693e20520698917/kendall-mann_construction-documents_Page_44.jpg)
![](https://freight.cargo.site/t/original/i/2e2c6911a63b98d1322f964b06efd03a710ad27335427bc6b72db1e1639ab48d/kendall-mann_construction-documents_Page_45.jpg)
![](https://freight.cargo.site/t/original/i/1990fc55aac45e4d59b73e0d549ea1852fe02e8eb76e21d9b838f5c01c90ca89/kendall-mann_construction-documents_Page_46.jpg)
Produced with Tamara Birghoffer, Heyifan Jin, Yunbin Wang, Chengyu Zhang, and Zile Zhang
Instructed by Pavel Getov and Kerenza Harris
